How to Compare Specifications for a Single-Head Cabinet Door Drilling Machine

Choosing a single-head cabinet door drilling machine requires more than checking one performance figure. Buyers should compare the maximum borehole diameter, motor arrangement, cylinder travel, drill chuck apertures, compressed-air requirement, machine footprint, and total weight. Together, these specifications show whether the equipment suits hinge and handle drilling, workshop utilities, available floor space, and cabinet production needs.

Key Selection Points

• The maximum borehole diameter should cover the largest hole required for the cabinet doors in your production plan. This machine supports drilling up to 60 mm.
• Motor output and cylinder travel should be considered as a pair. The configuration includes two 2.2 kW motors and a 60 mm cylinder trip.
• Check tooling before purchase. The specified drill chuck apertures are 10 mm and 12.7 mm.
• Prepare the installation area and utilities in advance. The machine requires 0.6-0.8 MPa air pressure, measures 1700 x 800 x 1600 mm, and weighs 300 kg.

This automatic hinge and handle drilling machine is designed for single-head cabinet door processing. It can be considered for panel furniture and customized home furnishing applications, including wardrobe and kitchen cabinet manufacturing. Its specifications should be evaluated as one complete production and installation package.

How the Main Specifications Affect Selection

Drilling capacity

The stated maximum borehole diameter is 60 mm. Compare this limit with the largest hinge cup, handle hole, or other opening needed for the cabinet doors being manufactured. If the required diameter is larger than the machine's capacity, an additional drilling operation or another machine may be necessary.

Power and drilling travel

The machine uses two 2.2 kW motors, while the cylinder trip is 60 mm. These values indicate the specified power and travel configuration, but they should still be assessed together with the door material, panel construction, and intended drilling method. The available information does not specify spindle speed, production rate, or applicable workpiece thickness, so these points should be confirmed separately.

Tool and air-system compatibility

Drill selection is limited by the listed 10 mm and 12.7 mm chuck apertures. Confirm that the shank sizes of the drills required for hinge and handle work fit these apertures. The workshop must also provide a stable compressed-air supply within the stated 0.6-0.8 MPa range.

Workshop layout and handling

The overall dimensions are 1700 x 800 x 1600 mm, and the machine weighs 300 kg. These figures should be used when planning delivery routes, floor positioning, loading and unloading areas, operator access, maintenance clearance, and lifting or moving equipment.

Specification Comparison Table

Quality and Project Support

Foshan Sun Hunt Woodworking Machinery Co.,Ltd. states that its quality-control process includes precision calibration, extended load-running tests, inspections of mechanical clearance and positioning accuracy, and control-program optimization before shipment. The company also reports project experience involving a 19-machine wood-door factory line in India and a 10-machine wood-processing line in the UAE. Feedback from these projects described stable machine operation and responsive after-sales assistance.

Frequently Asked Questions

What is the maximum hole diameter supported by the machine?

The specified maximum borehole diameter is 60 mm.

Which drill chuck sizes are available?

The listed chuck apertures are 10 mm and 12.7 mm. Buyers should compare these sizes with the shanks of the drills used for their planned hinge and handle operations.

What should be prepared before installation?

The site should provide compressed air at 0.6-0.8 MPa, sufficient floor space for a 1700 x 800 x 1600 mm machine, and safe handling capacity for its 300 kg weight. Clearance for operation and maintenance should also be included in the layout.

Is the machine suitable for customized furniture production?

It is intended for cabinet door drilling and can be considered for panel furniture and custom home furnishing production, such as wardrobes and kitchen cabinets. The actual suitability should be verified against the required hole sizes, tools, materials, and production method.

Conclusion

Before ordering, compare the intended process with every major specification: the 60 mm maximum borehole diameter, two 2.2 kW motors, 60 mm cylinder trip, 10 mm and 12.7 mm chuck apertures, 0.6-0.8 MPa air requirement, 1700 x 800 x 1600 mm footprint, and 300 kg weight. Foshan Sun Hunt also states that it can provide non-standard customized machines and complete production-line solutions. With a minimum order quantity of one set and a stated delivery time of 15 days, the machine may suit both individual equipment purchases and broader cabinet production projects. For technical consultation or support, contact vincent@fsshmachine.cn.
